ESG450-4T 18-inch Silicon Ingot Cropping Saw
- Description
- Inquiry
Description
ESG450-4T 18″ Silicon Ingot Cropping Single Wire Saw
Breif Introduction :
ESG450-4T is designed to be a Silicon Ingot Cropping Single Wire Saw,The loading table is soft material which is suitable for brittle material.It’s especially convenient for Silicon ingot cropping.This machine uses diamond wire loop as cutting tool,high linear speed and small wire diameter ensures better cutting surface and less kerf loss.
The cutting speed of this machine is parabolic type,material breakage and wire marks can be highly reduced.Contact us to get more info about silicon ingot cropping diamond wire saw.
Parameter
| Machine Size | 2000*1300*2300mm(L*W*H) |
| Machine Weight | 1000Kg |
| Electric | 220V |
| Power | 2.2KW |
| Motor Speed | 2800RPM |
| Positioning Accuracy | ±0.03mm |
| Wire Length | 3232mm |
| Max Linear Speed | 37m/s |
| Sample Maximum Dimension | 1400*450*450mm(L*W*H) |
| Loading Capacity | 700Kg |
| Feed Speed | 1-900mm/min |
| Cutting Method | Dry and Wet |
| Feed Method | Stepping |
Product Features
- Made to do 18″ etc.Silicon ingot cropping , it’s an 2 axis machine which can cut certian length section automatically.
- The machine body is waterproof which can do wet cut.
- The tensioning system adopts adaptive tensioning system, there is no need to make tension force calculation.
Application of ESG450-4T
①、Endless diamond wire as cutting tool,faster linearspeed and faster cutting speed.
②、Two minites to install a new cutting wire
③、Less chipping and breakage.
④、Small kerf loss. wire dia 0.3 to 0.6 mm
⑤、One -directlion cut ,without commutation pattern thecutting surface is very good.
In addition, our cutting equipment can also be used for cutting Various metal and non-metallic composite materials, glass, rock, jade, monocrystalline silicon, silicon carbide, ceramics Epoxy board and other materials, especially suitable for cutting high priced and easily broken high hard brittle materials!If you have material cutting needs, you can contact us!
Guiding wheels——This Rubber Coated wheel /pulley is made for endless diamond wire saw.There are some stock model and we can also provide customized spec .The Rubber Coated wheel have several wire grooves which increase the wheel’s life time.normally there are 3 wire grooves.
We can provide all part of endless wire saw machine to support machinery company build machines including endless cutting wire ,bearing,fiangeand so on.
Diamond Wire Loop——Diamond wire loop is a kind of flexibility cutting tool, Coating diamond crystals onto the steel wire surface, mainly used for cutting hard and brittle materials, such as: sapphire, ceramic, stone, silicon, etc.
Share your material, cutting size, and target accuracy with Ensoll. Our engineers will recommend the suitable diamond wire saw solution.
